For companies where a small number of plates are traded per day
PR Flat Storage System
The PR Flat storage system is the newest type of its kind. The PR Flat storage system has been specially developed for companies that trade a small number of plates per day. The machine has a lower handling speed and lift capacity than its predecessors in the MD series.
The PR Flat storage system has almost the same properties as the MD Flat storage system. It is a fully equipped machine with all the necessary options for handling plates and doors. The PR Flat storage system can be used for the import and / or export of 1 or more machine tools. In addition, the DSS Warehouse software works together with this machine.
Specifications
Material to be recorded
- Materials non-permeable to air, such as particle board coated and plywood
- Materials permeable to air, such as MDF, chipboard raw
- Workpiece weight: 150 kg maximum
- Chaotic stack positions
- Standard stack height 1,900 millimeters
- Plate length at least 2,000 millimeters
- Plate width at least 1,000 millimeters
